Lens set D28 F100 mm (pair)

Description

Description

Lens set D28 F100 mm to collimate a laser beam. The kit includes a pair of lenses with different types of curvature of surfaces: biconvex and convex-concave (meniscus). The kit is used in a collimator unit in Raytools® laser heads (BT210, BT210S, BM109), in machines from Bodor® and other manufacturers where this standard size is used.

Included:

The lenses are made of Fused Silica, have a diameter of 28 mm, and a focal length of 100 mm. It operates stably at a laser generation wavelength of 1060 – 1070 nm. An antireflective coating with a residual reflection coefficient of R<0.5% is applied to both surfaces of the lenses.

Advantages of using lenses from KAMITEKA:

• High temperature resistance thanks to high quality imported material,
• Large degree of laser beam transmission due to a technologically advanced double-sided antireflection coating
• Long service life,
• High efficiency.

The lenses are manufactured in compliance with all necessary quality standards, technical and geometric parameters of products of this type. As a result of application, the lens guarantees the preservation of design parameters for a long time and ensures high power operation of laser cutting equipment. KAMITEKA recommends changing lenses with a kit, eliminating the need for individual element selection and making it easier to install in collimator units.

The appearance may be different from what is indicated in the image.
